FLA Series
FLA 12280-EU
3.6kWh
Low Voltage
Up to 16 units
Floor-Mounted
Product Introduction
The battery system main using solar power system for family house.
It also have a with to controller the battery easily and protect our Household application timely.
It also have a with to controller the battery easily and protect our Household application timely.
Product Advantages
• LiFePO4: Higher safe performance and longer cycle life.
• Multiple Protection: Built-in smart BMS and Fuse.
• Flexible Installation: Floor-Mounted.
• Wide Compatibility: Compatible with leading inverter brands.
• High Scalability: Capacity up to 57.6kWh.
• Long Warranty:5 Years.
• Multiple Protection: Built-in smart BMS and Fuse.
• Flexible Installation: Floor-Mounted.
• Wide Compatibility: Compatible with leading inverter brands.
• High Scalability: Capacity up to 57.6kWh.
• Long Warranty:5 Years.
Model
FLA12280-EU
Operating Voltage
11.2-14.4V
Energy
3.6kWh
Scalability
Up to 16 units in parallel(57.6kWh)
Depth of Discharge(DOD)
≥95%
Cycle Life
≥6,000 Cycles
Communication
RS485 / CAN
Protection Level
IP21
Download
- [UN38.3 TEST Summary] FLS2F6D01G01 (FLA12280-EU)
- [UN38.3 TEST REPORT] FLS2F6D01U01 (FLA12280-EU)
- [MSDS] FLS2F6D01SDS01 (FLA12280-EU)
- [Hazard and Classification Identification] FLS2F6D01DI01 (FLA12280-EU)
- [GHS Label Design Report] FLS2F6D01P01 (FLA12280-EU)
- [Certificate for Safe Transport of Intended cargo by Road] FLS2F6D01YL501 (FLA12280-EU)
- [Certificate for Safe Transport of Goods by Sea] FLS2F6D01YM501(FLA12280-EU)
